175 776 Ft-tól
Integrated Board , Super X7SPE-HF-D525 Key Features ,1. Intel®, Atom&trade, D525 (DMI) ,2. Up to 4GB single channel unbuffered, , , , non-ECC DDR3 800/667MHz SO-DIMM ,3. 2x Intel 82574L Gigabit LAN ,4. 1 PCI-E 2.0 x4 (in x16 slot) ,5. Onboard Matrox G200eW video ,6. 1x 3.5", or Up to 2x 2.5", Internal Drives ,7. 200W Power Supply , Available Colors: Black , , , ,Drivers &, Utilities , , , , ,BIOS , , , , ,Tested Memory List , , , , ,Manuals Product SKUs SYS-5015A-EHF-D525 SuperServer 5015A-EHF-D525(Black) , Motherboard Super X7SPE-HF-D525 , Processor/Cache CPU Intel®, Atom&trade, ,D525 processor System Bus DMI , System Memory Memory Capacity Two 204-pin SO-DIMM sockets Supports up to 4 GB of unbuffered, non-ECC DDR3 800/667MHz SO-DIMM (Single Channel) Memory Type DDR3 800/667MHz unbuffered, non-ECC SO-DIMM DIMM Sizes 256 MB, 512 MB, 1 GB, 2GB Memory Voltage 1.5V only , On-Board Devices Chipset Intel ICH9R Intel 82574L SATA Intel ICH9R SATA 3.0Gbps Controller RAID 0, 1, 5, 10 support (Windows) RAID 0, 1, 10 support (Linux) IPMI Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support Nuvoton WPCM450 BMC Network Controllers 2x Intel 82574L Gigabit Ethernet Supports 10BASE-T, 100/1000BASE-TX, RJ45 output Graphics Onboard Matrox G200eW video Super I/O Winbond 83627DHG chip , Input / Output Serial ATA 6 Serial ATA ports ( 3Gbps ) LAN 2x RJ45 LAN port USB 8x USB 2.0 / 1.1 compatible 2 rear + 3 headers (5 ports) + 1 Type A connector VGA D-Sub 15 Keyboard / Mouse PS/2 keyboard and mouse ports Serial Ports 1x Fast UART 16550 serial port 1x Serial Header Power Port 1x DOM Power connector , System BIOS BIOS Type 8Mb SPI Flash EEPROM with AMI BIOS BIOS Features Plug and Play (PnP) DMI 2.3 PCI 2.2 ACPI 1.0 / 2.0 / 3.0 USB Keyboard support SMBIOS 2.3 , Drive Bays Internal Bay 1x 3.5", Internal Drive Bay (Standard) OR 2x 2.5", Internal Drive (Optional) OR 1x 2.5", Internal Drive (Optional) Chassis Form Factor 1U Rackmount Model CSE-502L-200B , Dimensions Height 1.7", (43mm) Width 17.2", (437mm) Depth 9.8", (249mm) Gross Weight 10 lbs (4.5kg) Available Colors Black , Front Panel Buttons Power On/Off button System Reset button LEDs Power LED Hard drive activity LED 2x Network activity LEDs System Overheat LED I/O Ports Standard System I/O(Mouse, Keyboard, 2x USB Video, COM, LPT, LAN) , Expansion Slot PCI-Express 1 (x4) PCI-e 2.0 slot (in x16 slot) , Power Supply 200W Low Noise AC-DC power supply with PFC AC Voltage 100 - 240V, 50-60Hz, 3-1.5 Amp Max +5V 16.0 Amp +5V standby 2.0 Amp +12V 15.0 Amp -12V 0.8 Amp +3.3V 17.0 Amp , PC Health Monitoring CPU Monitors for CPU Cores, +3.3V, +5V, +12V, +3.3V Standby, VBAT, Memory, Chipset CPU Core 1-Phase-switching voltage regulator with auto-sense from 0.8375V-1.6000V FAN Total of four 4-pin fan headers 4 x fans with tachometer monitoring Status monitor for speed control Status monitor for on / off control Support 3-pin fans (without speed control) Low noise fan speed control Pulse Width Modulated (PWM) fan conn. Temperature Monitoring for CPU and chassis environment CPU thermal trip support Thermal Control for 4 x Fan Connectors I2C temperature sensing logic Thermal Monitor 2 (TM2) Support LED CPU / System Overheat LED Other Features Chassis intrusion Detection Chassis intrusion Header SDDC Support , Operating Environment / Compliance RoHS RoHS Compliant 6/6, Pb Free Environmental Spec. Operating Temperature: 0°,to 35°,C Non-operating Temperature: -40°,to 70°,C Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5 to 95% (non-condensing) See Parts List Parts List - (Items Included) , Part Number Qty Description Motherboard / Chassis MBD-X7SPE-HF-D525 ,CSE-502L-200B 1 ,1 Super X7SPE-HF-D525 Motherboard ,1U Black Chassis Cable 1 CBL-0061L 1 35CM, SATA CABLE, PB FREE, 26AWG, flat ,Riser Card RSC-RR1U-E16 1 RSC-RR1U-E16 with PCI-E x16 ou , , , , , , , , , , , Optional Parts List , Part Number Qty Description Hard Drive Bracket MCP-220-00051-0N ,MCP-220-00044-0N - ,- Retention Bracket for 1 x 2.5", HDD ,Retention Bracket for up to 2x 2.5", HDD
